LumiSun2 Series

Click to Expand

LumiSun2 Series

High quality Round LED Highbay light

Die Casted Heat Sink
The housing of the LumiSun2 LED high bay light is manufactured using a die-casting method with aluminum to achieve a sleek design, which allows for excellent heat dissipation. It is coated with UV light protection, which helps extend the product's lifespan. Our lights are produced with advanced technology, ensuring that their quality and durability far exceed those of standard LED high bay lights.
High-efficiency design
The LumiSun2 Series light is a high efficiency highbay with up to 140 lumens/watt due to the type and number of LED chips used. In addition to the efficiency, the LumiSun1 Series lamp has a lifespan of over 50,000 hours while maintaining at least 80% of the original brightness (L80).

Application Usecase

Specs Comparison

Here are the specifications for each model of LED high bay light in detail to help you choose the one that meets your needs. This information specifies the brightness, wattage, color temperature, and other features so you can compare and choose the most suitable lamp with confidence.

Model
LumiSun2-100
LumiSun2-120
LumiSun2-150
LumiSun2-200
LumiSun2-240
Power
100W
120W
150W
200W
240W
Lumens
14,000 lm
16,800 lm
21,000 lm
28,000 lm
35,000 lm
Efficiency
140 lm/w
140 lm/w
140 lm/w
140 lm/w
140 lm/w
Input Voltage
100-277 VAC
100-277 VAC
100-277 VAC
100-277 VAC
100-277 VAC
Color Temperature
6,500 K
6,500 K
6,500 K
6,500 K
6,500 K
CRI
>70
>70
>70
>70
>70
PF
>0.95
>0.95
>0.95
>0.95
>0.95
Beam Angle
90˚
90˚
120˚
120˚
120˚
IP Grade
IP 50
IP 50
IP 50
IP 50
IP 50

Benefits of Using LED Highbay Lights

High efficiency: Efficiency up to 140 lumens/watt with a lifespan of over 50,000 hours.
Durability: Made using die-casting methods with aluminum, providing good heat dissipation and coated with UV protection.
Installation location: Can be used to replace Metal Halide lamps in the same position immediately.
Comparison: LED High Bay Lights VS Metal Halide Lights
IP-65 standard prevents water damages.
Quality of the product ensures by TIS standard.
ISO 9001 Industrial quality products.
Power surge protection ensure the longevity.

Technical Information

This diagram shows the intensity of light produced by the arrangement of lamps, with installation at a height from the ground to a certain installation position and spacing between the lamps at a certain distance. This Intensity Light diagram illustrates the brightness values of all the lamps shining down onto the area.
Read more about Highbay installation.
